Power Supply Units

Power Supply Unit 20-27 Volt / 6.3 Amp (150W)

Features:

* Universal AC input / Full range (88...264 VAC 47-63Hz)
* Protections:Short circuit/Over load/Over voltage
* VOLTAGE ADJ. RANGE: 20-27 Volts
* Cooling by free air convection
* 100% full load burn-in test
* Fixed switching frequency at 25KHz
* DC output voltage: 20-27 Volt / 6.3 Amp
* Dimensions: 22 x 10 x 5,5 cm (LxBxH)

Price: EUR. 39,00 (SALE PRICE !!)
Type PW15024

RF HAMDESIGN ships Worldwide,
We will be glad to E-mail you a shipment quotation, or use the Quote request page



Power Supply Unit 24-30Volt / 22Amp (480W)

Features:

*
Universal AC input / Full range
* Built in active PFC function, PF>0.95
* Protections:Short circuit/Over load/Over voltage/Over temperature
* Forced air cooling by built-in DC fan
* High power density 5.18w/in
* Low profile: 43mm thickness
* VOLTAGE ADJ. RANGE 22 ~ 27.6V
* Built-in remote ON-OFF control
* Built-in remote sense function
* Active AC surge current limiting
* 3 years warranty

Price EUR. 195,00
Type: PW48024 (480W)

RF HAMDESIGN ships Worldwide,
We will be glad to E-mail you a shipment quotation, or use the Quote request page



Power Supply Unit 24-30Volt / 18Amp (500W)

Features:

*
Universal AC input/Full range: 88~264VAC 47~63Hz
* LOW COST, HIGH RELIABILITY
* COOLING FAN ON/OFF AUTOMATICALLY
* 100% FULL LOAD BURN-IN TEST
* BUILT IN REMOTE CONTRAL
* BUILT IN EMI FILTER
* VOLTAGE ADJ. RANGE: 24-30 Volts
* LOW RIPPLE NOISE
* HIGH EFFICIENCY
* BUILT IN PFC CIRCUIT
* SOFT-START CIRCUIT
* LIMITING AC SURGE CURRENT
* SHORT CIRCUIT, OVERLOAD, OVER VOLTAGE, OVER TEMP. PROTECTED
* Dimension: 170*120*93mm (L*W*H)
* Weight: 1.8Kg

Price EUR. 172,00
Type: PW50027 (500W)

* Available 500W serie: 12V-40A / 15V-32A / 24V-20A / 27V-18A / 48V-10A

RF HAMDESIGN ships Worldwide,
We will be glad to E-mail you a shipment quotation, or use the Quote request page



Power Supply Unit 24-30Volt / 27,8Amp (750W)

Features:

*
Universal AC input/Full range: 90 ~ 264VAC
* AC input active surge current limiting
* Built-in active PFC function,PF>0.95
* Protections:Short circuit, overload, over voltage, over temperature
* Forced air cooling by built-in DC ball bearing fan
* VOLTAGE ADJ. RANGE: 24-30 Volts
* Built-in constant current limiting circuit
* With power good and fail signal output
* Built-in remote ON-OFF control
* Built-in remote sense function
* High efficiency 90%
* Dimension: 278*127*63.5mm (L*W*H)
* Weight: 2.9Kg

Price EUR. 284,00
Type: PW75027 (750W)

* Available 750W serie: 12V-62A / 15V-50A / 24V-31A / 27V-27.8A / 48V-15.7A

RF HAMDESIGN ships Worldwide,
We will be glad to E-mail you a shipment quotation, or use the Quote request page



Power Supply Unit 24-30Volt / 56 Amp (1500W)

Features:

*
Universal AC input/Full range: 90 ~ 264VAC
* AC input active surge current limiting
* Built-in remote sense function
* Built-in 12V/0.1A auxiliary output for remote control
* Built-in remote ON-OFF control
* VOLTAGE ADJ. RANGE: 24-30 Volts
* Protections: Short circuit / Overload / Over voltage / Over temperature
* Forced air cooling by built-in fan
* Parallel operation is available by connection this PSU's ! (4* 1500W)
* High efficiency 90%
* Dimension: 278*127*83.5mm (L*W*H)
* Weight: 2.6Kg

Price EUR. 528,00
Type: PW150027 (1500W)

* Available 1500W serie: 5V-240A / 12V-125A / 15V-100A / 24V-63A / 27V-56A / 48V-32A

NEW:
Parallel operation is available by connection this series PSU's !
You can operate max 4 units parallel, for example: 1500W type, up to 6000W. (5Volts / 960A, 12Volts / 375A, 24Volts / 252A, 27Volts / 224A, 48Volts / 128A)
Mail for more info !


RF HAMDESIGN ships Worldwide,
We will be glad to E-mail you a shipment quotation, or use the Quote request page



Power Supply Unit 22-28Volt / 125Amp (3000W)

Features:

*
Universal AC input/Full range: 180 ~ 264VAC
* AC input active surge current limiting
* Built-in remote sense function
* Built-in 12V/0.1A auxiliary output for remote control
* Built-in remote ON-OFF control
* VOLTAGE ADJ. RANGE: 22-28 Volts
* Protections: Short circuit / Overload / Over voltage / Over temperature
* Forced air cooling by built-in fan
* Parallel operation is available by connection this PSU's ! (4* 1500W)
* High efficiency 90%
* Dimension: 278*177.8*63.5mm (L*W*H)
* Weight: 4Kg

Price EUR. 783,00
Type: PW300024 (3000W)

* Available 3000W serie: 12V-250A / 24V-125A / 48V-62.5A

NEW:
Parallel operation is available by connection this series PSU's !
You can operate max 4 units parallel, for example: 3000W type, up to 12000 Watts. (12Volts / 750A, 24Volts / 375A, 48Volts / 187,5A)
Mail for more info !
